Description
Brand Name: Evoke
Model Number: GALE-6963V
Warranty: 1 years
Special Features: Waterproof / Weatherproof
Sensor: CMOS
Style: Dome Camera
Function: Waterproof / Weatherproof
Video Compression Format: H.265
Data Storage Options: NVR
Application: Outdoor
Technology: NetWork
Resolution: 8.0MP
Image Sensor: 1/3″ CMOS
Lens: 3.6mm
Remote monitoring: Mobile phone/LED
IR Distance: 30M
Waterproof Level: IP67
Focus: Auto focus
Power Supply: DC12V
Technology Specification | ||
Image Device | 1/2.5″ C-MOS 8.0MegaPixel | |
Min Illumination | 0.0Lux(IR ON) | |
S/N Ratio | >48dB(Auto Gain Control ) | |
Electronic Shutter | AES ON:1/50~1/100,000 Sec | |
Infrared LED | 36pcs LED | |
Night Vision Distance | 30m | |
Lens | 3.6mm | |
Power Supply | DC 12V | |
Working Temperature | 60°C ~ -20°C | |
Video Compression Format | H.264,Support 1 route D1 @ 25 frame + 1 route CIF @ | |
25 frame double streaming | ||
Compression Output Bit Rate | Streaming 0.1 M ~ 2 Mpbs adjustable, 1 ~ 30 frames /second adjustable | |
Max Image Shows | D1/720P/1080P | |
Alarm | Motion detecting and the I/O alarm linkage | |
Support Protocol | TCP/IP,FTP,PPPOE,DHCP,DDNS/NTP/UPNP | |
Operate | real-time video transmission, front store and replay, | |
front- end video download, support motion detecting and the I/O alarm | ||
Remind and pictures pop-up display linkage; | ||
Support the client remote monitoring software (UC) | ||
Communication Interface | 1 route RJ45 10/100 M adaptive Ethernet interface | |
Video Output | 1.0 Vp-p composite image signal; 75 Ω BNC output interface | |
Interface | Support mobile HDD link; Support the front-end storage remote calls |
