8MP Waterproof IP Dome Camera


Model Number: GALE-6963V

8 in stock


Brand Name: Evoke

Model Number: GALE-6963V

Warranty: 1 years

Special Features: Waterproof / Weatherproof

Sensor: CMOS

Style: Dome Camera

Function: Waterproof / Weatherproof

Video Compression Format: H.265

Data Storage Options: NVR

Application: Outdoor

Technology: NetWork

Resolution: 8.0MP

Image Sensor: 1/3″ CMOS

Lens: 3.6mm

Remote monitoring: Mobile phone/LED

IR Distance: 30M

Waterproof Level: IP67

Focus: Auto focus

Power Supply: DC12V

Technology Specification
Image Device 1/2.5″ C-MOS 8.0MegaPixel
 Min Illumination 0.0Lux(IR ON)
S/N Ratio >48dB(Auto Gain Control )
Electronic Shutter AES ON:1/50~1/100,000 Sec
Infrared LED 36pcs LED
Night Vision Distance 30m
Lens 3.6mm
Power Supply DC 12V
Working Temperature 60°C ~ -20°C
Video Compression Format H.264,Support 1 route D1 @ 25 frame + 1 route CIF @
25 frame double streaming
Compression Output Bit Rate Streaming 0.1 M ~ 2 Mpbs adjustable, 1 ~ 30 frames /second  adjustable
Max Image Shows D1/720P/1080P
Alarm Motion detecting and the I/O alarm linkage
Operate real-time video transmission,  front store and replay,
front- end video download, support motion detecting and the I/O alarm
Remind and pictures pop-up display linkage;
Support the client remote monitoring software (UC)
Communication Interface 1 route RJ45 10/100 M adaptive Ethernet interface
Video Output 1.0 Vp-p composite image signal; 75 Ω BNC output interface
Interface Support mobile HDD link; Support the front-end storage remote calls
