| Image Sensor |
1/2.8” CMOS |
| Total Pixels |
2704(H) × 2104(V)Approx. 5.69M pixels |
| Effective Pixels |
2616(H) × 1964(V)Approx. 5.14M pixels |
| Scanning System |
Progressive |
| Resolution |
5MP/ 20FPS/25FPS |
| Min-illumination |
Color:DSS:0.00017LUX, BW DSS: 0.00008 LUX |
| Video Output |
Analog HD：AHD/TVI/CVI and CVBS(960H) Composite Output(75Ω/BNC),4 in 1 |
| SDI |
SD Ioutput：EX-SDI V1.0/2.0/3G |
| S/N Ratio |
More than 42Db(AGC off) |
| ACE & WDR |
Off/Low/Middle/High; WDR SNR: 120Db |
| Lens |
Motor/DC/Manual/ fixed |
| Brightness |
0-20 steps |
| AGC |
0-20 steps |
| SENS-up |
Off/X2/X4/X8/X16/X32 |
| Shutter Speed |
AUTO/MANUAL(1/50\60 ~ 1/60,000 sec) |
| Defog |
Off/On, Low/Middle/High |
| BLC |
Off/BLC |
| HLC |
Off/HLC |
| Day & Night |
Auto/Color/B&W/EXTERN |
| Color (AWB) |
Auto/Auto ext/Preset/Manual |
| Monitor |
1/2/3 |
| 3D-DNR |
Off/Low/Middle/High |
| Mirror |
Off/Low/Middle/High |
| H-V-REV |
Off/On |
| Sharpness |
Off/On |
| Motion |
0-10steps |
| Privacy Mask |
16 Masks More |
| Language |
English |
| Power(Max.) supply |
DC12V±10%<1.6W（<130mA） |
| EX-SDI distance |
BNC cable 75-3 can reach 350m above |
| Size |
127*127mm(H) |
