| Model |
: GLA432855383 |
| Image Sensor |
: 2.4 COMS |
| DSP |
: FH8536H |
| Scanning System |
: Progressive |
| Resolution |
: 1932(H) ×1088(V) |
| Effective Pixels |
: 2.4MP |
| TV System |
: PAL/NTSC |
| Electronic Shutter |
: Auto/1/50(1/60)- 1/50,000sec |
| Sync System |
: Internal |
| Min. Illumination |
: 0.1LUX |
| Video output |
: AHD/TVI/CVI/CVBS |
| S/N |
: ≥50dB |
| Gamma Correction |
: 0.45 |
| Focus Length |
: 3.6mm/4mm |
| Auto Iris Support |
: NO |
| IR LED |
: 18pcs SMD leds |
| IR Distance |
: 20M |
| AES |
: Yes |
| AGC |
: Yes |
| D&N |
: Ext(default)/Auto / Color / B&W(OSD control) |
| BLC |
: Auto |
| DNR |
: 3DNR |
| DWDR |
: Support |
| OSD |
: Support |
| Flicker less |
: ON / OFF |
| Weatherproof Housing |
: IP67 |
| Electrical protection |
: Yes |
| Working Temperature |
: -20℃ — 50℃ |
| Storage Temperature |
: -30°C~60°C |
| Humidity |
: 20%~90% |
| Operating Voltage |
: DC12V/67mA ±6mA(wide voltage 9V-18V) |
